Find the right machine for the Job

  • New equipment from Link-Belt Excavators and Wacker Neuson
  • High quality excavators, wheel loaders, skid steers, CTLs, attachments, and more
  • Latest earthmoving and material handling technology
  • Comprehensive warranty packages available

Improve jobsite performance and boost your productivity with the full line of Link-Belt Excavators. Choose from their compact, large, and long reach models to find the best new equipment for the specific needs and requirements of your construction or earthmoving projects. Features like intelligent hydraulics increase power and decrease fuel use, while advanced telematics help you catch issues early and better manage your fleet. Plus, complete a wide range of jobs with the same machine using a variety of buckets and attachments with these excavators to complete your jobs efficiently.

When it comes to excavating, loading, and material handling, Wacker Neuson has a machine that’s right for your project. With wheel loaders, telescoping wheel loaders, skid steers, CTLs, and utility track loaders, you can work on jobsites of all sizes and easily load the tallest trucks and hoppers. Plus, with conventional, zero turn, and wheeled excavator models, you can find the best new equipment for your particular size, power, material, maneuverability, and traction requirements.

l1

Model Operating Weight Engine Output Bucket Digging Force


X4S Series With Auto Power Boost
Model Operating Weight Engine Output Bucket Digging Force
355 X4S 78,709 lb 205 HP 42,780 lbf


X4 Series
Model Operating Weight Engine Output Bucket Digging Force
130 X4 29,100 lb 102 HP 21,400 lbf
160 X4 38,400 lb 112 HP 26,500 lbf
210 X4 48,900 lb 160 HP 34,600 lbf
250 X4 56,900 lb 177 HP 39,570 lbf
300 X4 67,000 lb 207 HP 42,780 lbf
350 X4 82,400 lb 268 HP 56,160 lbf
490 X4 112,900 lb 362 HP 55,500 lbf
750 X4 158,300 lb 512 HP 68,790 lbf


Spin Ace Series With Auto Power Boost
Model Operating Weight Engine Output Bucket Digging Force
75 X3 17,400 lb 54 HP 12,800 lbf
80 X3 18,900 lb 54 HP 12,800 lbf
145 X4 33,600 lb 102 HP 21,400 lbf
245 X4 56,900 lb 160 HP 34,600 lbf


Heavy Duty
Model Operating Weight Engine Output Bucket Digging Force
210 X4 56,900 lb 160 HP 34,600 lbf
250 X4 68,400 lb 177 HP 39,570 lbf
300 X4 73,200 lb 207 HP 42,780 lbf


Long Front With Auto Power Boost
Model Operating Weight Engine Output Bucket Digging Force
210 X4 51,900 lb 160 HP 14,600 lbf
250 X4 63,600 lb 177 HP 17,300 lbf
350 X4 88,200 lb 268 HP 24,500 lbf

Wacker Neuson

image 1

Skid Steer Loaders
Model Operating Weight Engine Output Bucket Digging Force
SW20 6,435.3 lb 56.3 HP 5,300 lbf
SW21 6,510.3 lb 73.8 HP 5,300 lbf
SW32 8,628.9 lb 100.6 HP 9,461 lbf

image 2

Compact Track Loaders
Model Operating Weight Engine Output Bucket Digging Force
ST27 7,350.2 lb 74 HP 5,404 lbf
ST31 8,240.9 lb 74 HP 5,611 lbf
ST37 9,014.7 lb 74 HP 7,042 lbf
ST45 10,266.9 lb 74 HP 6,941 lbf
ST50 10,677 lb 100 HP 9,461 lbf

image 3

Utility Track Loaders
Model Operating Weight Engine Output Bucket Digging Force
SM60 2,760 lb 26.5 HP 2,498 lbf
SM100 3,300 lb 24.7 HP 3,110 lbf
SM120 3,754 lb 24.7 HP 3,235 lbf

image 4

image 5

Wheel Loaders
Model Operating Weight Bucket Capacity Heaped Tipping Load
5055 7,936.6 lb 19.42 ft3 4,365.2 lb
8085 10,472 lb 30.02 ft3 7,363.4 lb
WL28 7,275 lb 14.83 ft3 5,820 lb
WL38 9,480 lb 22.6 ft3 8,199 lb
WL52 11,244 lb 30.02 ft3 8,706 lb
WL60 13,074 lb 35.31 ft3 8,100 lb
WL95 22,906 lb 54.74 ft3 14,394 lb
Telescopic Wheel Loaders
8085T 12,125.4 lb 30.02 ft3 7,275.3 lb

image 5

image 6

image 7

Excavators
Model Operating Weight Engine Output Bucket Digging Force
Tracked Conventional Tail Excavators
803 2,458.2 lb 13.3 HP 2,000.8 lbf
ET20 5,568.9 lb 18.5 HP 4,226.4 lbf
ET42 11,477.3 lb 43.6 HP 9,846.6 lbf
ET58 14,078.7 lb 44.9 HP 10,341.2 lbf
ET65 16,221.6 lb 56.3 HP 11,397.8 lbf
ET90 23.161.8 lb 74.3 HP 16,635.9 lbf
ET145 38,084.9 lb 73.8 HP 20,457.6 lbf
Zero Tail Excavators
EZ17 4,592.2 lb 18.5 HP 4,203.9 lbf
EZ26 7,403.1 lb 19.6 HP 5,076.2 lbf
EZ36 10,901.9 lb 24.4 HP 7,868.3 lbf
EZ50 12,908.1 lb 43.6 HP 8,273 lbf
Wheeled Excavators
EW65 14,892.2 lb 61 HP 11,398 lbf
EW100 26,579 lb 73.8 HP 12,162.2 lbf
